Basic Usage

The image component renders optimized images with semantic HTML. The src can be passed as a positional argument (recommended) or keyword argument.

Basic Usage

<%# Simple image (positional src argument - recommended) %>
<%= rui_image("photo.jpg", alt: "A beautiful sunset") %>

<%# Alternative: keyword argument for src %>
<%= rui_image(src: "photo.jpg", alt: "A beautiful sunset") %>

<%# Image with caption (uses figure/figcaption) %>
<%= rui_image(
  "landscape.jpg",
  alt: "Mountain vista",
  caption: "View from the summit at sunrise"
) %>

<%# Linked image %>
<%= rui_image(
  "product.jpg",
  alt: "Product name",
  url: product_path(@product)
) %>

Simple image with lazy loading and async decoding

Semantic HTML (Figure & Caption)

When you provide a caption, the image automatically uses semantic <figure> and <figcaption> elements.

Without Caption

<img src="..." alt="...">

With Caption

Foggy mountains — Morning mist over the valley

<figure>
  <img src="..." alt="...">
  <figcaption>...</figcaption>
</figure>

Image with Caption

<%= rui_image(
  "photo.jpg",
  alt: "Sunset over the ocean",
  caption: "Malibu Beach - Summer 2024"
) %>

Sizes

Control image dimensions with preset sizes.

xs (64px)

sm (96px)

md (128px)

lg (192px)

Size Options

<%= rui_image(url, alt: "Photo", size: :xs) %>   <%# 64px %>
<%= rui_image(url, alt: "Photo", size: :sm) %>   <%# 96px %>
<%= rui_image(url, alt: "Photo", size: :md) %>   <%# 128px %>
<%= rui_image(url, alt: "Photo", size: :lg) %>   <%# 192px %>
<%= rui_image(url, alt: "Photo", size: :xl) %>   <%# 256px %>
<%= rui_image(url, alt: "Photo", size: :full) %> <%# 100% width %>

Social Media Platform Sizes

Built-in presets for common social media image dimensions (based on 2025 guidelines). These presets include the correct aspect ratio automatically.

Note

When using platform sizes, the aspect ratio is automatically applied. The ratio parameter is ignored for platform sizes.

Instagram

:ig_post (1:1)

:ig_post_portrait (4:5)

:ig_story (9:16)

:ig_post_landscape (1.91:1)

Facebook

:fb_post (1:1)

:fb_story (9:16)

:fb_cover (2.7:1)

X (Twitter)

:x_post (16:9)

:x_post_square (1:1)

:x_header (3:1)

LinkedIn

:linkedin_post (1.91:1)

:linkedin_post_square (1:1)

:linkedin_cover (5.9:1)

Other Platforms

:pin (2:3)

:tiktok_post (9:16)

:yt_thumbnail (16:9)

:pin_square (1:1)

Social Media Platform Sizes

<%# Instagram %>
<%= rui_image("campaign.jpg", alt: "Summer campaign", size: :ig_post) %>
<%= rui_image("story.jpg", alt: "New product", size: :ig_story) %>
<%= rui_image("reel.jpg", alt: "Tutorial", size: :ig_reel) %>

<%# Facebook %>
<%= rui_image("post.jpg", alt: "Announcement", size: :fb_post) %>
<%= rui_image("cover.jpg", alt: "Company cover", size: :fb_cover) %>

<%# X (Twitter) %>
<%= rui_image("news.jpg", alt: "Breaking news", size: :x_post) %>
<%= rui_image("banner.jpg", alt: "Profile banner", size: :x_header) %>

<%# LinkedIn %>
<%= rui_image("article.jpg", alt: "Industry insights", size: :linkedin_post) %>

<%# Pinterest %>
<%= rui_image("recipe.jpg", alt: "Recipe idea", size: :pin) %>

<%# TikTok %>
<%= rui_image("video.jpg", alt: "Dance tutorial", size: :tiktok_post) %>

<%# YouTube %>
<%= rui_image("thumb.jpg", alt: "Video title", size: :yt_thumbnail) %>

Shapes

Four shape options for different visual styles.

Default

shape: :default

Rounded

shape: :rounded

Circle

shape: :circle

Square

shape: :square

Aspect Ratios

Force images to specific aspect ratios for consistent layouts.

ratio: :square (1:1)

ratio: :landscape (4:3)

ratio: :video (16:9)

Aspect Ratio Options

<%= rui_image(url, alt: "Photo", ratio: :square) %>    <%# 1:1 %>
<%= rui_image(url, alt: "Photo", ratio: :video) %>     <%# 16:9 %>
<%= rui_image(url, alt: "Photo", ratio: :portrait) %>  <%# 3:4 %>
<%= rui_image(url, alt: "Photo", ratio: :landscape) %> <%# 4:3 %>
<%= rui_image(url, alt: "Photo", ratio: :wide) %>      <%# 16:9 %>
<%= rui_image(url, alt: "Photo", ratio: :ultrawide) %> <%# 21:9 %>

Object Fit

Control how images fill their container.

fit: :cover

fit: :contain

fit: :fill

Object Fit Options

<%= rui_image(url, alt: "Photo", fit: :cover) %>      <%# Crop to fill (default) %>
<%= rui_image(url, alt: "Photo", fit: :contain) %>    <%# Letterbox %>
<%= rui_image(url, alt: "Photo", fit: :fill) %>       <%# Stretch %>
<%= rui_image(url, alt: "Photo", fit: :none) %>       <%# Natural size %>
<%= rui_image(url, alt: "Photo", fit: :scale_down) %> <%# Shrink only %>

Visual Effects

Apply hover-activated visual effects to images. Hover over the images below to see the effects.

grayscale: true

Hover to see color

blur: true

Hover to unblur

sepia: true

Hover for color

zoom: true

Hover to zoom

shine: true

Hover for shine

overlay: true

Hover for overlay

Combining Visual Effects

<%# Combine multiple effects %>
<%= rui_image(
  "photo.jpg",
  alt: "Team member",
  grayscale: true,
  zoom: true,
  shape: :rounded
) %>

<%# Professional team photo with grayscale + zoom %>
<%= rui_image(
  @member.photo_url,
  alt: @member.name,
  grayscale: true,
  zoom: true,
  shape: :circle
) %>

Linked Images

Make images clickable by providing a URL.

Click the images (they're linked)

Linked Images

<%= rui_image(
  @product.image_url,
  alt: @product.name,
  url: product_path(@product),
  shape: :rounded,
  zoom: true
) %>

<%# With caption %>
<%= rui_image(
  @product.image_url,
  alt: @product.name,
  caption: "#{@product.name} - #{number_to_currency(@product.price)}",
  url: product_path(@product)
) %>

Performance Attributes

Built-in performance optimization with lazy loading and async decoding.

Default Behavior (Optimized)

loading="lazy" - Defers loading until near viewport
decoding="async" - Non-blocking image decode
fetchpriority="auto" - Browser decides priority

Above-the-Fold Images (Hero)

For images visible immediately on page load, disable lazy loading:

Hero Image (Eager Loading)

<%# Hero image - load immediately %>
<%= rui_image(
  "hero-banner.jpg",
  alt: "Welcome to our store",
  size: :full,
  loading: :eager,
  fetchpriority: :high,
  decoding: :sync
) %>

Prevent Layout Shift

Always provide width and height to prevent content jumping:

Prevent Layout Shift

<%= rui_image("photo.jpg", alt: "Photo", width: 800, height: 600) %>

Responsive Images

Serve different image sizes for different screen widths.

Responsive srcset

<%= rui_image(
  "photo.jpg",
  alt: "Responsive photo",
  srcset: "photo-320.jpg 320w, photo-640.jpg 640w, photo-1280.jpg 1280w",
  sizes: "(max-width: 600px) 100vw, (max-width: 1200px) 50vw, 33vw",
  width: 1280,
  height: 960
) %>

Cross-Origin Images

For images from CDNs or other domains:

Cross-Origin Images (CORS)

<%= rui_image(
  "https://cdn.example.com/image.jpg",
  alt: "CDN image",
  crossorigin: "anonymous",
  referrerpolicy: "no-referrer"
) %>

Picture Element

The <picture> element provides advanced image handling for art direction and format fallback. Unlike srcset on a regular image (which serves different sizes of the same image), <picture> allows serving completely different images for different scenarios.

When to Use Picture vs srcset

srcset on img: Same image, different sizes (resolution switching)
picture: Different images for different viewports (art direction)
picture: Modern format (AVIF/WebP) with JPEG fallback
picture: Different images for dark/light mode

Format Fallback (AVIF/WebP with JPEG fallback)

Serve modern, smaller formats to browsers that support them, with automatic fallback. The images look identical but have different file sizes.

Note

Format fallback requires actual different format files on your server. The browser picks the first supported format. Images appear identical - only the file size/quality differs. Check DevTools Network tab to see which format loaded.

Format Fallback

<%# AVIF → WebP → JPEG (images look the same, different sizes) %>
<%= rui_image(
  "photo.jpg",
  alt: "High quality photo",
  sources: [
    { srcset: "photo.avif", type: "image/avif" },
    { srcset: "photo.webp", type: "image/webp" }
  ]
) %>

Art Direction (Different Images for Different Viewports)

Show completely different images based on screen size. Resize your browser window to see the image change:

Responsive hero - resize browser to see different images

≥1024px: Foggy valley (wide landscape)

640-1023px: Forest path (medium)

<640px: Mountain peaks (portrait - fallback)

Try it!

Drag your browser window smaller/larger to see completely different images load. This is art direction - not just resizing the same image.

Art Direction

<%# Different images per viewport %>
<%= rui_image(
  "mobile-portrait.jpg",
  alt: "Product showcase",
  sources: [
    { srcset: "desktop-wide.jpg", media: "(min-width: 1024px)" },
    { srcset: "tablet-medium.jpg", media: "(min-width: 640px)" }
  ]
) %>

Dark Mode Images

There are two approaches for dark mode images, depending on how your site handles theming:

Approach 1: CSS-based (works with site theme toggle)

If your site uses a JavaScript theme toggle (like data-theme="dark"), use Tailwind's dark: classes to show/hide images:

Light theme: Sunny beach | Dark theme: Starry night sky

Try it!

Toggle the site's dark mode (top right) to see the image change. This works with JavaScript theme toggles.

CSS-based Dark Mode (Recommended)

<%# Works with JavaScript theme toggles %>
<div class="relative">
  <%# Light mode image %>
  <div class="block dark:hidden">
    <%= rui_image("logo-light.png", alt: "Logo") %>
  </div>
  <%# Dark mode image %>
  <div class="hidden dark:block">
    <%= rui_image("logo-dark.png", alt: "Logo") %>
  </div>
</div>

Approach 2: Picture element (OS preference only)

The prefers-color-scheme media query only responds to the operating system's dark mode setting, not JavaScript theme toggles:

Important

prefers-color-scheme: dark only detects your OS dark mode setting (System Preferences → Appearance). It does NOT respond to website theme toggles that use data-theme or class-based switching.

Picture Element (OS Preference Only)

<%# Only works with operating system dark mode setting %>
<%= rui_image(
  "logo-light.png",
  alt: "Company logo",
  sources: [
    { srcset: "logo-dark.png", media: "(prefers-color-scheme: dark)" }
  ]
) %>

Picture Element with Caption

Combine picture element with semantic figure/figcaption. Resize your browser to see different images with the same caption:

Team member - responsive portrait — Sarah Chen - CEO & Co-founder

≥768px: Wide banner crop | <768px: Square portrait

Picture with Caption

<%= rui_image(
  "team-member-square.jpg",
  alt: "Team member portrait",
  caption: "Sarah Chen - CEO & Co-founder",
  sources: [
    { srcset: "team-member-wide.jpg", media: "(min-width: 768px)" }
  ],
  shape: :rounded,
  alignment: :center
) %>

Source Options Reference

Key	Required	Description
srcset	Yes	Image source(s) for this source element
media	No	Media query (e.g., "(min-width: 1024px)", "(prefers-color-scheme: dark)")
type	No	MIME type (e.g., "image/avif", "image/webp")
sizes	No	Responsive sizes for this source
width / height	No	Dimension hints for the browser

Responsive srcset within Source

Combine art direction with responsive sizing. Each source can have its own srcset with multiple resolutions:

Art Direction + Responsive Sizes

<%# Different images per viewport, each with multiple sizes %>
<%= rui_image(
  "hero-mobile.jpg",
  alt: "Hero banner",
  sources: [
    {
      srcset: "hero-desktop-800.jpg 800w, hero-desktop-1200.jpg 1200w, hero-desktop-1600.jpg 1600w",
      media: "(min-width: 1024px)",
      sizes: "(min-width: 1400px) 1400px, 100vw"
    },
    {
      srcset: "hero-tablet-600.jpg 600w, hero-tablet-900.jpg 900w",
      media: "(min-width: 640px)",
      sizes: "100vw"
    }
  ],
  width: 1600,
  height: 900
) %>

High DPI / Retina Images

Serve higher resolution images for retina displays using density descriptors (1x, 2x, 3x):

Retina / High DPI

<%# Serve 2x and 3x images for high DPI displays %>
<%= rui_image(
  "logo.png",
  alt: "Company logo",
  sources: [
    { srcset: "logo.png 1x, logo@2x.png 2x, logo@3x.png 3x" }
  ]
) %>

<%# Combined with art direction %>
<%= rui_image(
  "product-mobile.jpg",
  alt: "Product image",
  sources: [
    {
      srcset: "product-desktop.jpg 1x, product-desktop@2x.jpg 2x",
      media: "(min-width: 768px)"
    },
    {
      srcset: "product-mobile.jpg 1x, product-mobile@2x.jpg 2x"
    }
  ]
) %>

Combined: Art Direction + Format Fallback

The most advanced use case - different images per viewport, each with modern format fallbacks:

Art Direction + Format Fallback

<%# Different images for desktop/mobile, with AVIF/WebP fallback %>
<%= rui_image(
  "hero-mobile.jpg",
  alt: "Product showcase",
  sources: [
    # Desktop: wide image with format fallback
    { srcset: "hero-desktop.avif", media: "(min-width: 1024px)", type: "image/avif" },
    { srcset: "hero-desktop.webp", media: "(min-width: 1024px)", type: "image/webp" },
    { srcset: "hero-desktop.jpg", media: "(min-width: 1024px)" },
    # Tablet: medium image with format fallback
    { srcset: "hero-tablet.avif", media: "(min-width: 640px)", type: "image/avif" },
    { srcset: "hero-tablet.webp", media: "(min-width: 640px)", type: "image/webp" },
    { srcset: "hero-tablet.jpg", media: "(min-width: 640px)" },
    # Mobile: format fallback only (no media query)
    { srcset: "hero-mobile.avif", type: "image/avif" },
    { srcset: "hero-mobile.webp", type: "image/webp" }
  ]
) %>

Generated HTML

HTML Output

<picture>
  <source srcset="photo.avif" type="image/avif">
  <source srcset="photo.webp" type="image/webp">
  <img src="photo.jpg" alt="Description" loading="lazy" decoding="async">
</picture>

Real-World Examples

Product Gallery

Product Gallery

<div class="grid grid-cols-4 gap-4">
  <% @products.each do |product| %>
    <%= rui_image(
      product.image_url,
      alt: product.name,
      ratio: :square,
      shape: :rounded,
      zoom: true,
      url: product_path(product)
    ) %>
  <% end %>
</div>

Team Member Grid

CEO

CTO

Designer

Engineer

Team Member Grid

<div class="grid grid-cols-4 gap-6">
  <% @team_members.each do |member| %>
    <div class="text-center">
      <%= rui_image(
        member.photo_url,
        alt: member.name,
        caption: member.name,
        size: :lg,
        shape: :circle,
        grayscale: true,
        alignment: :center
      ) %>
      <%= rui_text(member.role, size: :sm, color: :muted, class: "mt-1") %>
    </div>
  <% end %>
</div>

Blog Post Image

How We Built Our Design System

Computer setup with code on screen — Our engineering team's workspace

Building a comprehensive design system requires careful planning and collaboration across teams...

Accessibility

The Image component follows WAI-ARIA best practices for accessible images.

ARIA Attributes

alt attribute required for meaningful images (describes content)
alt="" for decorative images (hidden from screen readers)
role="img" implicit on <img> elements
Linked images inherit accessible name from alt text

Keyboard Navigation

Linked images are focusable via Tab
Enter activates linked images
Focus ring visible on linked images for keyboard users

Semantic HTML

Native <img> element for standard images
<figure> + <figcaption> for images with captions
<picture> element for responsive art direction
Proper loading="lazy" and decoding="async" for performance

Screen Reader Support

Alt text announced when image is encountered
Captions associated with images via <figcaption>
Linked images announced as "link, image" with alt text

Example: Accessible Image Patterns

Accessible Image Examples

<%# Meaningful image with descriptive alt text %>
<%= rui_image("team-photo.jpg", alt: "Marketing team celebrating product launch") %>

<%# Decorative image (hidden from screen readers) %>
<%= rui_image("decorative-border.png", alt: "") %>

<%# Image with caption (uses figure/figcaption) %>
<%= rui_image(
  "chart.png",
  alt: "Sales growth chart showing 45% increase",
  caption: "Q4 2024 sales performance by region"
) %>

<%# Linked image (alt text describes destination) %>
<%= rui_image(
  "product.jpg",
  alt: "View Blue Widget product details",
  url: product_path(@product)
) %>

API Reference

rui_image

Semantic HTML image with captions, links, visual effects, and picture element support

Parameter	Type	Default	Description
src*	String	—	Image source URL (positional or keyword)
alt*	String	—	Alt text for accessibility
caption	String	—	Caption text (triggers figure/figcaption)
url	String	—	Link URL (makes image clickable)

Sizing

Size and dimension options

Parameter	Type	Default	Description
size	Symbol	`:auto`	Size preset `:auto` `:full` `:xs` `:sm` `:base` `:lg` `:xl` `:xl2` `:xl3`
width	Integer/String	—	Width in pixels or CSS value
height	Integer/String	—	Height in pixels or CSS value
aspect	Symbol	—	Aspect ratio `:square` `:video` `:wide` `:portrait` `:auto`

Appearance

Visual styling options

Parameter	Type	Default	Description
shape	Symbol	`:square`	Corner style `:square` `:rounded` `:pill` `:circle`
fit	Symbol	`:cover`	Object fit behavior `:cover` `:contain` `:fill` `:none` `:scale_down`
filter	Symbol	—	CSS filter effect `:grayscale` `:sepia` `:blur` `:brightness` `:contrast`
hover_effect	Symbol	—	Hover effect `:zoom` `:brighten` `:darken` `:grayscale_to_color`

Performance

Loading and performance options

Parameter	Type	Default	Description
loading	Symbol	`:lazy`	Loading behavior `:lazy` `:eager`
srcset	String	—	Responsive source set
sizes	String	—	Responsive sizes attribute
sources	Array	—	Picture element sources for art direction

Platform Sizes

Social media preset sizes

Parameter	Type	Default	Description
:ig_post	Preset	—	Instagram post (1080x1080)
:ig_story	Preset	—	Instagram story (1080x1920)
:fb_cover	Preset	—	Facebook cover (820x312)
:twitter_header	Preset	—	Twitter header (1500x500)
:og_image	Preset	—	Open Graph (1200x630)

Image vs Avatar

Use Image for:

Content images (photos, illustrations)
Images with captions
Gallery images
Product images
Hero banners
Blog post images

Use Avatar for:

User profile pictures
Team member photos (no caption)
Status indicators (online/offline)
Grouped/stacked avatars
Fallback to initials or icon
Social media platform sizes

Related Components

Avatar

User profile pictures with status indicators

Badge

Labels for status or categories on images

Link

Wrap images in semantic links

Key Features

Basic Usage

Semantic HTML (Figure & Caption)

Sizes

Social Media Platform Sizes

Note

Instagram

Facebook

X (Twitter)

LinkedIn

Other Platforms

Shapes

Aspect Ratios

Object Fit

Visual Effects

Linked Images

Performance Attributes

Default Behavior (Optimized)

Above-the-Fold Images (Hero)

Prevent Layout Shift

Responsive Images

Cross-Origin Images

Picture Element

When to Use Picture vs srcset

Format Fallback (AVIF/WebP with JPEG fallback)

Note

Art Direction (Different Images for Different Viewports)

Try it!

Dark Mode Images

Approach 1: CSS-based (works with site theme toggle)

Try it!

Approach 2: Picture element (OS preference only)

Important

Picture Element with Caption

Source Options Reference

Responsive srcset within Source

High DPI / Retina Images

Combined: Art Direction + Format Fallback

Generated HTML

Real-World Examples

Product Gallery

Team Member Grid

Blog Post Image

Accessibility

ARIA Attributes

Keyboard Navigation

Semantic HTML

Screen Reader Support

Example: Accessible Image Patterns

API Reference

rui_image

Sizing

Appearance

Performance

Platform Sizes

Image vs Avatar

Use Image for:

Use Avatar for:

Related Components

Avatar

Badge

Link
